Metal VSP Ring
AceChemPack Metal VSP Ring also called Very Special Pall Ring which is a new type of tower random packing. During plant operation the VSP Ring create gas/liquid contact on easily wettable surfaces and promote the formation of droplets as the liquid cascades through the packed bed. This ensures good liquid mixing and consistent and uniform distribution. This open non-testing structure creates high efficiency and a very low pressure drop. AceChemPack Metal VSP Ring is available in a wide range of carbon steel and stainless steels.
Material: Stainless steel, carbon steel, aluminum, copper and other alloy.
Specifications:
|
Type |
Quantity n/m³ |
Specific Surface (a) m2/m3 |
Free Volume (ε) m³/m³ |
|
25mm |
52500 |
250 |
0.93 |
|
38mm |
14500 |
138 |
0.95 |
|
50mm |
7000 |
121 |
0.95 |
|
76mm |
1950 |
75 |
0.95 |
* Thickness of metal VSP ring could be specified by customer.
